News From LogicSwap

LogicSwap to offer CADSTAR PCB to IPC-2581 CAM format

The IPC-2581 standard is a harmonization of GenCAM 1.5 and the Valor©OBD++ format. This next generation CAM format is quickly becoming a standard among FAB houses due to its support for process definitions within a single file.

This new Utility for CADSTAR is planned for June 2008.


LogicSwap offers Migration Solutions for PADS PowerPCB © and Allegro© PCB to CADSTAR PCB.

Due to increasing EDA market demand for CADSTAR, LogicSwap will be adding two new Migration Solutions.

  •   MGC, PADS PowerPCB© to CADSTAR© PCB
  •   Cadence Allegro PCB© to CADSTAR© PCB
    •

These new solutions will be available on the LogicSwap 2008 Series Launchpad.

In the mean time, PADS Power PCB --> CADSTAR PCB and Cadence Allegro PCB --> CADSTAR PCB services are available for "Proof of Concept" migrations.

Users of MGC DX Designer©, EPD© and Viewlogic© --> CADSTAR Schematic Capture require LogicSwap's EDIF to CADSTAR CSA module.

In the tradition of LogicSwap Solutions "Proof of Concept" opportunity, one small migration will be performed free of charge. Simply contact us. Non-Disclosure Agreements are welcomed and encouraged.

Address and Contact Information


204 West Cummings Park - Suite #6
Woburn MA 01801
e-mail: Info@logicswap.com
Main Phone : 781-560-8170
Fax : 781-577-0343
Mobile : 978-828-6059

   Click menu buttons to access Migration Solutions

Welcome to the New and Improved LogicSwap Solutions website for 2008

This year we have invested in a new method of providing Migration Services and Support using a personalized approach. Effective immediately, all Visitors are allowed to create a User account with us at No Charge! Our intention is be able to provide a secure environment where Customers can Upload and track their design files. In addition to a secure Upload and Download experience, we have introduced a new Shopping cart style environment to automate the purchasing of Products and Services. The intent is to help you to generate a temporary quotation which will be forwarded to You to expedite your purchasing process.

Start by Logging in and creating a new User account. Once you have been activated you will be free to upload your designs to our new Secure FTP server. Once your files are uploaded, our Sales and Support members will be notified immediately and called to Action.

Large Scale Migration Projects with LogicSwap

LogicSwap is frequently approached to address large scale Corporate Evolution Migrations. Reasons include;

  •  Overwhelming workload

  •  Fear of designs not working as they did with previous  CAD systems

  •  Internal costs of labor versus outsourcing.

  •  It just makes sense to leave it to the Professionals

LogicSwap Solutions understands these reasons and has taken the opportunity to create a new Migration Project datasheet to explain how you can get started with your Corporate Evolution to Zuken's CADSTAR environment. First, your copy and then to begin your Corporate Evolution Migration Project.

The Latest LogicSwap 2008 Series Updates are Available to Download!

We are constantly working to add functionality and make improvements to LogicSwap to support the latest versions of CADSTAR. Once you have downloaded the 2008 Series, You will see see that we have re-organized the Main Launchpad. We have also added New Netlist extraction utilities for CADSTAR. If you have not installed the latest LogicSwap suite, please feel free at your convenience.

The 2008 Series provides demonstration capability using supplied design files.
